Placing the drill in the chuck. Turn off the power of hammer drill. For hammer drilling and chiselling,
SDS-plus tools are required that are inserted in the SDS-plus drill chuck.
The SDS-plus drill chuck allows for simple and convenient changing of drilling tools without the use
of additional tools.
Insert the SDS-plus quick. Clean and lightly grease the shank end of the tool. Insert the tool in a
twisting manner into the tool holder until it latches itself. Check the latching by pulling the tool. As a
requirement of the system, the SDS-plus drilling tool can move freely. This causes a certain radial run-out
at no-load, which has no effect on the accuracy of the drill hole, as the drill bit centres itself upon drilling.
Removing SDS-plus drilling tools. Push back the locking sleeve and remove the tool.
Turn on and off.
Pay attention to mains voltage! The supply voltage must correspond to the data on the rating plate.
Appliances marked with 230 V can also be powered with a voltage of 220 V.
Change grease
Approximately 60 hours of work (about 5,000 drilled holes) should be completed with 8-10 grams of
grease. Open the grease cap Place lithium grease with viscosity 2NLGI / National lubricating greace
institute /
For prolonged storage of the breaker, grease should be checked and, if oxidised, changed.
9. Turn the machine.
On - Press power trigger (poz.A)
Off - Free electric trigger (poz.A)
10. Auxiliary handle.
WARNING! Udarniyat breaker RD-HD03 is equipped with a protective system in wedge or pinch
the working tip during operation. However, it is unacceptable use of instruments without MOUNTED
HANDLE MORE!
Auxiliary handle (poz.B) allows safe and stable operation. Setting the position you need done lightly,
simply unscrew the handle, place it in the desired position and retighten.
11. Depth.
With the help of depth akutratno can adjust the depth of the bores.
12. Modes of operation.
WARNING! NEVER change the behavior AT WORK THE MACHINE!
- Mode "Hammer drilling"
Press the release button and turn the switch operating modes into position
(fig.1)
- Mode "Chiselling"
Press the release button and turn the switch operating modes into position
(fig. 2)
- Mode "Setting the drill"
Press the release button and turn the switch operating modes into position
13. Sharpening chisels.
