PREPARATION - BEFORE INSTALLATION:
1. APPLICATION SOLUTION: Fill 32oz. trigger type spray bottle
with 20% Alcohol 80% Water add 2ml of Baby Shampoo.
Note: Solution depends on temperature of part,
temperature of vehicle surface and other factors. Note: more
soap makes it easier for the squeegee to slide bubbles out
from under the part when installing.
2. This product should be installed with proper installation tools.
3. Install this product while observing all warnings and precautions
stated in this instruction booklet.
4. VERY IMPORTANT: Thoroughly wash vehicle with Soap and
Water.
5. Parts storage should be flat at room temperature and in a clean
dry place. Care should be taken to avoid a dusty environment.
Rear Bumper
Horizontal Bumper Surface
1 Clean
Thoroughly wash vehicle Surface with a soft lint-free cloth.
Allow the area to dry completely.
Handling Tab
Handling Tab
Appliqué
Applique
3
Separate Liner
Remove liner from Bumper Appliqué. After removal of part liner,
to prevent contamination, limit touching adhesive side of Appliqué
by handling on the Handling Tabs. Spray Alcohol, Soap and Water
Application Solution on Adhesive Side of the Appliqué.
DESCRIPTION
Rear Bumper Appliqué
Handling Tab
Handling Tab
Liner
Liner
Appliqué
Applique
ISSUE
00
Notes to the Installer
1.
Read the entire installation instructions prior to beginning the
installation of the accessory.
2.
Ensure that the vehicle is properly protected in the area that
the accessory is to be installed.
3.
To prevent vehicle damage, never place tools on top of painted
surfaces, seats, dash pad, console or floor carpet / mat.
4.
Always wear appropriate safety gear to include gloves and eye
protection when required.
2
Dry Fit
Before removing liner, locate the center notch in the appliqué
directly under the center of the bumper as shown above.
Align the top of Handling Tabs to vertical surface. Then align the
bottom to the end of the tangent near the curved edge
and lay into position.
4
Spray Bumper Surface
Spray bumper surface where applique will be installed with
Application Solution.
DATE
SUBARU OF AMERICA
10/15/20
PAGE
2 / 8
