Robby STEAM UP Manuel D'utilisation page 17

ASSEMBLY :
1) Install the Diffusion Head Holder on the top of the Foldable
Hanger (Fig. 1)
2) Install the foldable support at the top of the telescopic
mast. (Fig 2)
3) Desserrez le verrou de la base, insérez le bras télescopique,
puis re-serrez le verrou. (Fig. 3)
3) Loosen the base latch, insert the telescopic arm, and re-
tighten the latch. (Fig. 3)
5) Install the steam pipe into the unit, turn clockwise to lock
it. (Fig. 5)
6) To remove lint and dust, place and clip the brush onto the
diffuser head. (Fig. 6)
OPEN
sav@robby.fr
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6
p.17
