2-1/4" Button
Head Socket
Locknut
Washer
Q
Bolt
O
J
Large Pivot
Arm Shim
K
Small Pivot
Arm Shim
Q
Cover Plate
Locknut
Anchor
Figure 7
Q
Locknut
R
Plastic Shim
Washer
Figure 8
Install bracket mounting
screws from here forward
CMVXLR/XLRP-FR 241024
G
Figure 6
Ballstud Mounting
Plate
Y
Rubber
P
Bumper
Front Pivot
D
Arm
Rear Pivot
Arm
2-1/4" Button
Y
Head Socket
Rubber
Bolt
I
Bumper
2" Button
P
Head Socket
Washer
Ball Stud
Mounting
Plate
W
Shock
Position this screw hole
just forward of/adjacent
to the corner skirt panel
of the spa
Figure 9
AE
Vanish XLR/
XLRP Filler
U
Screw
C
Figure 10
O
S
Hex
Cap Bolt
Bolt
#12
Maintenant, ouvrez complètement la couverture et fixez les vis de
N
montage n° 10 x 1½" restantes aux supports de montage (Fig. 8).
#13
Fixez les plaques de recouvrement (H) aux supports de montage à
l'aide des vis de montage n° 10 x 1" (U). Ensuite, vissez le boulon hexagonal
3/8 x 3/4" dans le trou de la plaque qui s'aligne avec le bras pivotant arrière
(Fig. 10). Attention : Ne serrez pas trop le boulon.
Operation of your Covermate Vanish XLR/XLRP
1) Ouvrez la couverture et pliez-le en deux. Soulevez ensuite la couverture
et abaissez-la derrière le spa.
ATTENTION!
ITEM
PART#
G
A(L)
101733
A(R)
101734
B(L)
101854
B(R)
101855
C
101737
D
101738
E
101850/101851 VANISH XLR PIVOT ARM PLATE - FRONT
101856/101857
F
101973/101974
G(L)
101741
G(R)
101742
H(L)
101743
H(R)
101744
I
101745
J
101746
K
101747
L
100244
M
100032
N
101749
O
101758
P
100012
Q
100011
R
101750
S
101752
T
100909
U
100014
V
100015
W
101446/101447 SHOCK - 600N/700N
X
100016
Y
101762
Z
101650
AA
101552
AB
101751
AC
102146
AD
101996
AE(L)
100577
AE(R)
100578
N'utilisez pas le CoverMate par grand vent. Des blessures peuvent survenir lorsque le couvercle
du spa est renversé et qu'il heurte l'utilisateur du spa.
DESCRIPTION
VANISH XL BASE BRACKET (L)
VANISH XL BASE BRACKET (R)
CM VANISH XLR COVER MOUNTING BRACKET (L)
CM VANISH XLR COVER MOUNTING BRACKET (R)
VANISH XL PIVOT ARM - FRONT
VANISH XL PIVOT ARM - REAR
VANISH XLR/XLRP PIVOT ARM PLATE - REAR
BALL STUD MOUNTING PLATE - LEFT
BALL STUD MOUNTING PLATE - RIGHT
VANISH XL COVER PLATE (L)
VANISH XL COVER PLATE (R)
VANISH XL COVER PLATE ANCHOR
LARGE PIVOT ARM SHIM
SMALL PIVOT ARM SHIM
5/16 BALL STUD
5/16 NYLON LOCKNUT
3/8 X 2" BUTTON HEAD SOCKET BOLT - BLACK ZINC
3/8 X 2-1/4" BUTTON HEAD SOCKET BOLT
3/8 FLAT WASHER
3/8 NYLON LOCKNUT
3/8 PLASTIC SHIM WASHER
3/8 X 3/4" HEX CAP BOLT - BLACK ZINC
#10 X 1-1/2" PHILIPS PAN HEAD MOUNTING SCREW
#10 X 1" PHILIPS PAN HEAD SELF-TAPPING SCREW
LARGE BLACK DOME CAP
SMALL BLACK DOME CAP
RUBBER BUMPER
#8 X 1-1/4" PHILIPS FLAT HEAD SELF-TAPPING SCREW - BLACK ZINC
COVERMATE VANISH XL HANDLE
5/16 X 1-1/4" BUTTON HEAD SOCKET BOLT
CM VANISH XLR/XLRP ALUMINUM PLATE INSERT
#10 X 1" PHILIPS PAN HEAD SELF-DRILLING SCREWS
VANISH XLR/XLRP FILLER (L)
VANISH XLR/XLRP FILLER (R)
AD
Screw
H
Cover
Plate
U
Mounting
Screws
QTY
1
1
1
1
2
2
1
1
1
1
1
1
2
4
4
4
4
4
4
6
8
8
2
68
32
2
2
32
4
4
2
2
2
8
1
1
