• AC Amps can be measured in any position of the rotary selector dial.
• Center wire in guides for best accuracy.
• Opposing currents cancel each other (use line-splitter when necessary).
• Keep hands below guard when measuring high current levels.
• Do not attempt to measure more than 600A AC.
Features:
AC Amps Measurement - Jaw input
Range
60.00A 0.01A
600.0A 0.1A
45Hz to 400Hz True RMS
Minimum Current for Clamp Measurement: 0.3A
AC Amps <600A Jaw
RANGE RANGE
AUTO AUTO
True RMS True RMS
SELECT SELECT
Resolution
MAX/MIN MAX/MIN
Low Z
V
CLAMP METER CLAMP METER
INRUSH INRUSH
DISCONNECT TEST LEADS DISCONNECT TEST LEADS
TEMP
TEMP
CATIV 300V
CATIV 300V
CATIII 600V CATIII 600V
Accuracy
±2.0% + 8dgts
8
Single
Conductor
Only
• Rotary selector dial =
any position
• Reading show on
upper display
Overload Protection
600V RMS
