UEi Test Instruments DL579 Manuel D'instructions page 12

• Buzzer sounds at less than < 40Ω.
WARNING
• Do not measure resistance on a live circuit.
Features:
Open circuit voltage < 0.64V
Threshold Approx : < 40Ω
Features:
WARNING
• Do not measure resistance on a live circuit.
Range Resolution
600.0Ω 0.1Ω
6.000kΩ 0.001kΩ
60.00kΩ 0.01kΩ
600.0kΩ 0.1kΩ
6.000MΩ 0.001MΩ
60.00MΩ 0.01MΩ
Continuity
RANGE MAX/MIN
AUTO
AUTO
Ω
True RMS
CLAMP METER
SELECT INRUSH
DISCONNECT TEST LEADS
TEMP
CATIV 300V
CATIII 600V
SELECT
BT
Resistance: < 60MΩ
RANGE MAX/MIN
AUTO
AUTO
kΩ
True RMS
CLAMP METER
SELECT
DISCONNECT TEST LEADS INRUSH
TEMP
CATIV 300V
CATIII 600V
SELECT
BT
Accuracy
±1.0% + 4dgts
±2.0% + 4dgts
• Default =
• Press SELECT x1 =
Overload Protection
600V RMS
• Default =
• Press RANGE to
select resolution
12
Overload Protection
600V RMS
