2021 - present F150 CrewCab XLT and SuperCab XLT
NOTE: Model with instrument panel grill
shown. Model without instrument panel
grill similar.
Pry loose the center dash trim
bezel.
Use the General Equipment: Interior Trim
Remover
Audio Front Control Module Removal
Remove the four bolts pictured.
There are two additional bolts securing
the bottom of the module not pictured.
Torque: 22 lb.in (2.5 Nm)
Page 6 of 22
Contact KICKER
Technical Support at (800) 256-0808 ext. 6009, or oesupport@kicker.com.
®
Wire Harness Connection to ACM
Connector
Disconnect the connector
indicated
Using a pick tool, slide the
terminal retainer out on both sides until
it stops.
© Copyright Ford 2022 FoMoCo
