2021 - present F150 CrewCab XLT and SuperCab XLT
115mm
Razor Knife
Front of
Vehicle
327mm
Install bracket. Torque: 46
lb.in. (5.2Nm)
Lower the subwoofer into
position aligning the plastic fastener
with bracket hole.
Install bolt. Torque: 46 lb. in.
(5.2 Nm)
Page 11 of 22
Contact KICKER
115mm
338mm
X2
Technical Support at (800) 256-0808 ext. 6009, or oesupport@kicker.com.
®
Install supplied retainer around
harness at the position marked with blue
tape. Trim the excess length of the
retainer. Attach the retainer over the
stud.
NOTE: Screws and metal retainers are pre-
installed in upper bracket and designed to
snap into sheet metal as assembled. Do not
remove screws or metal retainers during
installation.
Cut Carpet to allow upper
bracket retainers to snap into metal.
1. Press on upper bracket to snap metal
retainers into sheet metal.
Connect harness to amplifier.
© Copyright Ford 2022 FoMoCo
