• Compatible with halogen recessed downlights up to 50 watts
(except sealed downlights and with fixed installation wiring
insulation, supplied with the lighting unit, resistant to a minimum
of 120°C).
• Designed solely for installation above recessed downlights. Not
suitable for protecting converters, transformers or terminals.
• Suitable for ceiling cut-outs with a recessed diameter of 62 to
90 mm.
• The diameter of the drill hole must match the diameter of the
downlight + 4 mm to enable the support arms of the SpotClip-I
to fit through.
• The maximum available height is 70 mm.

3 Operator responsibilities

The operator must comply with the legal directives applicable at
national level and also the directives relating to the prevention of
accidents. The use of a SpotClip-I, does not mean the operator is
exempt from consulting the instruction sheet for the downlight used.
In case of uncertainty, please contact a qualified professional.

4 Transportation and storage

Do not stack heavy objects on the packaged product.
5 Product assembly view
Diagram is a an assembly view of the product. Diagrams
A
show the details of the product. All the product diagrams are
provided on the fold-out page.
Legends for , and
A B
Mounting brackets to support the power supply wire
1
Support arms
2
Retaining lugs
3
Operating manual • SpotClip-I • 08-2016
Operator responsibilities
:
C
and
B C
