MA grandMA3 onPC command wing Manuel Rapide page 23

Outputs grandMA3 onPC command wing
grandMA3 onPC command wing rear panel
Number Connector
1 x IEC connector
2 x DMX512-A OUT (5pin XLR female)
1 x DMX512-A IN (5pin XLR male)
1 x MIDI IN (5pin DIN female)
1 x MIDI OUT (5pin DIN female)
1 x LTC – Linear Time Code (3pin XLR female)
1 x GPI – General Purpose Input (D-SUB DE9 female – DC remote control)
1 x USB 2.0 (type B)
1 x LED desk light (4pin XLR female)
23
