W-200 INTEGRA_ PRESSURE and SUCTION SPRAY GUNS
1. DESCRIPTION OF THE PRODUCT
The ANEST IWATA spray guns is an instrument designed according to the most Innovative
Spray Painting Technologies for the application of all types of paints, atomized by mean the
use of compressed air. The ANEST IWATA spray gun meets the widest range of different
applications in Automotive and General Industry applications sectors.
2. IMPORTANT INFORMATIONS
IMPORTANT
WARNING
Before use, adjustment or maintenance, it is important to read this instruction manual
very carefully. This manual must be stored in a safe place for any future reference.
COMPLIANCE TO STANDARD OF SPRAY GUN
ANEST IWATA Spray Guns comply with 2014/34/EU Directive relating to equipment and pro-
tective systems intended for use in explosive potentially atmospheres.
COMPLETE COMPLIANCE MARKING:
II 2 G Ex h IIB T6 Gb X +5°C ≤ Ta ≤ + 40°C
II 2 G Ex h X
ABBREVIATED COMPLIANCE MARKING ON THE SPRAY GUN:
II 2 G Ex h X
II 2 G Ex h X
ALWAYS OBSERVE WARNINGS AND CAUTIONS IN THIS MANUAL
SYMBOL
WARNING
WARNING
CAUTION
IMPORTANT
3. TECHNICAL SPECIFICATION
MODELS
Max. working air pressure:
Weight g (lbs):
Noise level (LAeqT)*:
Air Connection
Fluid Connection
Max. Temperature range:
* Measuring point: 1m backwards from gun, 1.6 m height.
3
This manual is an integral part of pressure spray gun and must to be read
carefully before starting ANY ACTIVITY involving the use, adjustment
and maintenance of the equipment, including its handling.This manual
must be stored in a safe place for any future reference.
Be sure to observe warnings and cautions in this instruction manual.
If not, it can cause paint ejection and serious bodily injury by drawing
organic solvent.
Our spray guns, airbrushes, and other products are made to conform by
our local group companies with local laws and regulations that may dif-
fer from place to place. Improper trade of products outside of designated
domestic territories (unauthorized reselling) can result in legal violations,
local fines, and penalties. ANEST IWATA assumes no liability for prod-
ucts acquired through unauthorized reselling and in such cases and due
to quality control protocols, unauthorized reselling renders the warranty
null and void.
HAZARD LEVEL
POTENTIALLY
HAZARDOUS
SITUATION
DEATH OR SERIOUS INJURY
MINOR TO MODERATE INJURY
PROPERTY DAMAGE
W-200 INTEGRA
PRESSURE
7.0 bar (100 PSI)
375 (0.83)
80 dB(A)
G1/4" (NPS1/4)
G3/8" (NPS3/8)
Atmosphere 5 ~ 40 °C / Air-Fluid 5 ~ 43 °C
CONSEQUENCE
W-200 INTEGRA
SUCTION
GB
