Tool Specifications
Wet Tile Saw
Article number
Input power
No-load speed
Blade diameter
Hole
Max. sawing height
Max. sawing length
Saw table dim. (LxB)
Dimensions (LxBxH)
Weight
Safety class
Operating Controls
1
Motor
2
On/Off switch
3
Motor flange
4
Saw flange
5
Flange nut
6
Capacitor
7
Pump
8
Knob f/ legs
9
Clamping lever
10 Guiding roll
11 Roll
12 Grip
13 PRCD protective switch*
14 Saw table lock
15 Thermal protection
Not all of the accessories illustrated or described are
included as standard delivery.
Intended Use
The sawing machine is only to be used for sawing
sandstones, concrete products and natural stone in
combination with wet-diamond blades and a suffi-
cient supply of water.
For damage caused by usage other then intended,
the user is responsible.
All manuals and user guides at all-guides.com
NTS 125
0701 412
2200 W
2800 RPM
Ø350 mm / Ø400 mm
Ø25,4 mm
Ø350 mm: 100 mm
Ø400 mm: 125 mm
500 mm
475 x 400 mm
1060 x 600 x 620 mm
approx. 62 kg
/ I
Before Use
Always use the correct supply voltage: The
power supply voltage must match the information
quoted on the tool identification plate.
On
construction
appliances should be connected to
specially
designed
Suitable are grounded main power
supplies equipped with an earthleak
switch of max. 30mA or separating
transformers.
Non-grounded common household or
similar power outlets are not suited as
a power source.
For water cooled sawing machines stricter safety
standards are applicable. Therefore, for extra safety
the machine must be connected according to one of
the following methods:
* Main power supply equipped with earthleak switch
30 mA.
--------------------- or ---------------------
* Separating transformer, only 1 machine may be
connected at any given time.
--------------------- or ---------------------
* With an intermediate cable equipped with a PRCD
safety switch of max. 30mA.
* Not included as standard delivery.
sites
electrical
power
supplies.
11
