DMX PROTOCOL - 11 CHANNELS
CHANNEL VALUE
CH1 0-255
CH2 0-255
CH3 0-255
CH4 0-255
CH5 0-255
0-159
CH6
160-255
0-119
CH7
120-255
0-99
CH8 100-127
128-255
0-126
CH9
127-255
0-59
CH10 60-159
160-255
CH11 0-255
DMX PROTOCOL - 13 CHANNELS
CHANNEL VALUE
CH1 0-255
CH2 0-255
CH3 0-255
CH4 0-255
CH5 0-255
CH6 0-255
CH7 0-255
0-159
CH8
160-255
0-119
CH9
120-255
0-99
CH10 100-127
128-255
0-126
CH11
127-255
0-59
CH12 60-159
160-255
CH13 0-255
CONTENT
Pan Running
Tilt Running
Running Speed in Pan/Tilt
Dimming
Strobe
Choose color
Change the color automatically from slow to fast
Fixed Gobo
Change the pattern automatically from slow to fast
Prism OFF
Prism effect - no rotation
Prism rotates from slow to fast
No effect
7 Color rainbow effect
No effect
Auto mode
Sound mode
Reset after 5seconds
CONTENT
Pan Running
Pan fine adjustment
Tilt Running
Tilt fine adjustment
Running Speed in Pan/Tilt
Dimming
Strobe
Choose color
Change the color automatically from slow to fast
Fixed Gobo
Change the pattern automatically from slow to fast
Prism OFF
Prism effect - no rotation
Prism rotates from slow to fast
No effect
7 Color rainbow effect
No effect
Auto mode
Sound mode
Reset after 5seconds
