Power Supply - Bresser TemeoTrend Sunny Mode D'emploi

(8) Wall-mount recessed hole – This hole makes
it possible to mount the main unit on a wall.
(9) Battery compartment
(10) Table stand – Add if station is to be placed
on a flat surface.
Remote sensor (Fig. 3)
(11) Outdoor temperature
(12) Battery compartment
(13) CH button – Channel is to be selected at
channel 1.
(14) Wall mount hole – This hole makes it
possible to mount the remote sensor on a wall.
(15) °C/°F button – This button selects between
Celsius (°C) and Fahrenheit (°F).
(16) Table stand – Use this stand to place the
device on a flat surface
BEFORE YOU START
IMPORTANT!
1. Insert batteries for remote units before doing so
for the main unit.
2. Place the main unit as close as possible to the
remote unit.
3. Position the remote unit and main unit within the
effective transmission range.
When changing batteries always change batteries
in the main unit as well as all remote units and
replace them in the correct order, so the remote
connection can be re-established. If batteries are
exchanged in only one of the devices (i.e. the
remote sensor) the signal can't be received or can't
be received correctly.
Note, that the effective range is vastly affected by
building materials and position of the main and
remote units. Due to external influences (various
RC devices and other sources of interference), the
maximum distance can be greatly reduced. In such
cases we suggest to position the main unit and the
remote sensor at other places. Sometimes all it
takes is a relocation of one of these components
of a few inches!
Though the remote unit is weather proof, it should
be placed away from direct sunlight, rain or snow.

POWER SUPPLY

Remote sensor
1. Open the battery compartment door.
2. Install 2 batteries (AAA size 1.5V) strictly
according to the polarities shown.
3. Press CH button to select the channel.
4. Reinsert the battery compartment door.
Main unit
1. Open the battery compartment door.
2. Install 3 batteries (AAA size 1.5V) strictly
according to the polarities shown.
3. Reinsert the battery compartment door.
Low battery warning
When it is time to replace the batteries, the
respective low battery indicator
near to the time display (batteries for main unit)
or near to the outdoor temperature (batteries for
remote sensor).
DE
GB
FR
IT
ES
will be shown
13
