FG Modellsport FUN CROSS WB535 Notice De Montage page 22

Best.Nr / Réf / Item N° 670060
FUN CROSS WB535
Best.Nr / Réf /
Item N° 670060R
FUN CROSS WB535 RTR
Pièces détachées
05785 Moteur FG F260
05304 Roulements F260, 2pcs
05310 Axe piston F260, 1pc
05312 Roulement aiguille F260, 1pc
05312/01 Entretoise centrage, 2pcs
05313 Vilebrequin F260, 1 pc
07336 Bride isolante, 1pc
05341 Carter moteur A F260, 1pc
05385/03 Segment F260, 1 pc
05701 Carter A+B, F260, 1pc
05706 Joint embase F260, 1pc
05715 Entrainement embrayage, 1pc
05715/01 Vis de support d'embrayage, 1pc
05716 Masselotte embrayage F260, 2pcs
05717 Ressort embrayage 2,6, 1pc
05718 Vis fixation masselottes, 2pcs
05728/02 Anti-parasite F260, 1pc
05730/08 Vis échappement M5x52, 2pcs
05731 Echappement Leopard RTR, 1pc
05734/08 Set visserie moteur F260
05742 Carter B F260, 1pc
05745 Carter d'embrayage montage debout, 1pc
05754/08 Entretoise F260, 1pc
05785/01 Cylindre 26cm3 F260, 1pc
05785/02 Piston 26cm3 F260, 1pc
06451/03 Adaptateur filtre à air, 1pc
06451/04 O-Ring adaptateur filtre à air, 2 pcs
06734/05 Rondelle acier 5.3, 15pcs
07303/08 Joint spy F260, 2pcs
07305/08 Joint carter F260, 1pc
07311 Circlips axe piston Zenoah, 2pcs
07313/01 Cale vilebrequin, 1pc
07314 Ecrou, 1pc
07319/08 Volant allumage F260, 1pc
07323/08 Lanceur pour F260, 1pc
07323/09 Carter lanceur F260, 1pc
07323/10 Ressort lanceur F260, 1pc
07323/11 Poulie lanceur F260, 1pc
07323/12 Ficelle lanceur F260, 1pc
07323/13 Poignée lanceur F260, 1pc
07323/14 Entrainement lanceur F260, 1pc
07323/15 Ressort de pression, 1pc
07323/16 Vis rondelles, 3pcs
07326/08 Circlips, 1pc
07328/08 Bobine allumage F260, 1pc
07332 Joint échappement F260, 1pc
07335 Joint isolateur, 1pc
07337 Joint bride isolante, 1pc
07339/08 Vis fixation carburateur F260, 2pcs
07340/08 Coupe circuit F260, 1pc
07340/09 Protection caoutchouc, 1pc
07343/08 Bougie CMR7H F260, 1pc
07344/08 Câble guide, 1pc
07355/08 Carburateur F260, 1pc
07361/08 Vis de richesse ressort F260, 2pcs
07362/08 Vis ralenti ressort F260 2PCS
07363 Set membrane, 2 pcs
07364 Couvercle carburateur, 1pc
07365/09 Vis ralenti ressort, 2pcs
07366/08 Axe boisseau+vis F260, 2pcs
07367/08 Boisseau carburateur F260, 1pc
07368 Ressort rappel carburateur, 1pc
07370 Membrane, 2pcs
07371 Pièce carburateur Zenoah, 1pc
07372 Fixation pompe amorçage, 1pc
07372/01 Vis pour fixation pompe, 4pcs
07373 Pompe amorçage, 1pc
07374 Commande de boisseau, 1pc
07375 Vis de palonnier du carburateur, 1pc
07377/08 Axe starter/vis F260, 2pcs
07378/08 Volet starter F260, 1pc
07379/08 Levier starter F260, 2pcs
T2M SAS HOBBY MODELLBAU Vertriebs GmbH
ZI - Avenue André Gouy - BP 30006 Winterbergstraße 24a
57381 FAULQUEMONT CEDEX 66119 SAARBRÜCKEN
Tél : +33 (0)3 87 29 25 20
Telefon : 0681-51733
Fax : +33 (0)3 87 94 37 22
Telefax : 0681-51735
info@t2m.tm.fr hobby@t2m.tm.fr
www.t2m-rc.fr www.t2m-rc.fr/de
www.fg-modellsport.com www.fg-modellsport.de
Spare parts
05785
05304
05310
05312
05312/01
05313
07336
05341
05385/03
05701
05706
05715
05715/01
05716
05717
05718
05728/02
05730/08
05731
05734/08
05742
05745
05754/08
05785/01
05785/02
06451/03
06451/04
06734/05
07303/08
07305/08
07311
07313/01
07314
07319/08
07323/08
07323/09
07323/10
07323/11
07323/12
07323/13
07323/14
07323/15
07323/16
07326/08
07328/08
07332
07335
07337
07339/08
07340/08
07340/09
07343/08
07344/08
07355/08
07361/08
07362/08
07363
07364
07365/09
07366/08
07367/08
07368
07370
07371
07372
07372/01
07373
07374
07375
07377/08
07378/08
07379/08
- 22 -
Engine FG F260
Bearings, 2 pcs.
Gudgeon pin F260, 1 pce.
Needle bearing, 1 pce.
Spacer washer, 2 pcs.
Crankshaft complete, 1 pce.
Insulator, 1 pce.
Engine housing A, 1 pce.
Piston ring 26ccm, 1 pce.
Crank case housing A+B, 1 pce.
Cylinder gasket, 1 pce.
Clutch block carrier, 1 pce.
Screw for carrier, 1 pce.
Clutch blocks, 2 pcs.
Clutch spring, 1 pce.
Dowel screws f. clutch blocks, 2 pcs.
Spark plug cap, 1 pce.
Screws f. silencer M5x52, 2 pcs.
Silencer Leopard RTR, 1pce.
Screw set engine
Engine housing B, 1 pce.
Coupling flange vertical
Spacer block, 1 pce.
Cylinder 26ccm, 1 pce.
Piston 26ccm, 1 pce.
Air filter adapter, 1 pce.
O-rings f. air filter adapter, 2 pcs.
Washers, steel 5.3mm, 15 pcs.
Seal ring, 2 pcs.
Crankshaft gasket, 1 pce.
Gudgeon pin clips, 2 pcs.
Key for crankshaft, 1 pce.
Hexagon nut, 1 pce.
Cooling fan, 1 pce.
Pullstart unit complete, 1 pce.
Starter housing complete, 1 pce.
Spring assembly, 1 pce.
Rope pulley, 1 pce.
Rope, 1 pce.
Starter handle, 1 pce.
Starter ratchet, 1 pce.
Pressure spring, 1 pce.
Screws/disks, 3 pcs.
Securing ring, 1 pce.
Ignition coil, 1 pce.
Silencer gasket, 2 pcs.
Insulator gasket, 1 pce.
Carburetor gasket, 1 pce.
Screws f. carburetor, 2 pcs.
Circuit breaker, 1 pce.
Protect. cap circuit breaker, 1 pce.
Spark plug, 1 pce.
Cable bushing, 1 pce.
Carburetor, 1 pce.
Needle(full-speed)/ spring, 2 pcs.
Needle(idle speed)/ spring, 2 pcs.
Diaphragm, 2 pcs.
Carburetor cover, 1 pce.
Throttle screw /spring, 2 pcs.
Valve shaft with screw, 2 pcs.
Valve, 1 pce.
Leg spring, 1 pce.
Diaphragm set, 2 pcs.
Plastic part with carb. nipple, 1 pce.
Metal part f. pump, 1 pce.
Screws f. metal part, 4 pcs.
Pump, 1 pce.
Carburetor arm, 1 pce.
Screw f. carburetor arm, 1 pce.
Choke shaft w. screw, 2 pcs.
Choke flap, 1 pce.
Choke lever, 2 pcs.
