General working instructions
Before using the model, transmitter and receiver batteries need to be charged.
The charging time is indicated in the instruction manual of the charger.
One battery charge is sufficient for 1 - 2 tank fillings, depending upon the model and the location (street or open country). If you want to achieve
longer driving times and shorter charging times, you can install batteries with higher capacity and 12 V quick-chargers. Such chargers also allow a
recharging on the field with a car battery. Charge or respectively discharge a new battery before the first use at least three times. This is neces-
sary for the formatting of the single battery cells. Without this procedure, the battery could not develop its full capacity.
For the initial startup of the vehicle, please stick to the following sequence:
Switch on the transmitter - turn on the power supply of the receiver, then start the engine. After use please proceed in reverse order.
Before every operation of the vehicle, it is necessary to check the range of the RC equipment. Place the model within the distance you'd like to run
it. Do not operate the model in a distance of more than 100 meters! The model should respond to all signals of the transmitter. If not, do not run the
model! The vehicle or respectively the radio control is equipped with a fail safe function. Pay attention the fail safe function of your transmitter is set
in a way that the vehicle slows down and runs straight ahead in the case of interferences.
Protect RC equipment and battery against wet conditions. If you operate your model in the rain or on a wet driving surface, you must avoid water
entering the transmitter or the receiver.
Only use oil for 2 stroke engines, avoid oil for 4 stroke! Mixing ratio 1:33 = 3% oil share
5 liter fuel = 0,15 liter oil (150ml)
1 liter fuel = 0,03 liter oil (30 ml)
To prevent a sooting of the spark plug and the associated starting problems, please proceed in the following way:
If possible run your model around 5 times over a long straight line at full speed. If not possible, lift up the model, holding the roll bar and speed up
to full speed repeatedly for a few seconds. This will clean the spark plug and the engine will start without any problem the next time. If the engine-
remains difficult to start, clean the spark plug as described.
Check that all screws are tight before every startup. Secure metric screws screwed into metal with threadlock.
Montageanleitung für die RC-Anlage, nicht gültig für RTR-Modelle.
Notice de montage de l'ensemble RC, non valable pour les modèles RTR.
Mounting instruction of RC system, not valid for RTR models.
06546/01
T2M SAS HOBBY MODELLBAU Vertriebs GmbH
ZI - Avenue André Gouy - BP 30006 Winterbergstraße 24a
57381 FAULQUEMONT CEDEX 66119 SAARBRÜCKEN
Tél : +33 (0)3 87 29 25 20
Telefon : 0681-51733
Fax : +33 (0)3 87 94 37 22
Telefax : 0681-51735
info@t2m.tm.fr hobby@t2m.tm.fr
www.t2m-rc.fr www.t2m-rc.fr/de
www.fg-modellsport.com www.fg-modellsport.de
68245
06126
- 13 -
06598
06597
