CONTRINEX BASIC DW-AS-60x-C44 Manuel D'utilisation

HOUSING OPERATING DISTANCE
40 x 40 mm 15 mm
DETECTION DATA
Rated operating distance (S )
n
Assured operating distance (S
a
Repeat accuracy
Hysteresis
Temperature drift
Standard target
ELECTRICAL DATA
Supply voltage range (U )
B
Residual ripple
Output current
Output voltage drop
Power consumption (no-load)
Residual current
Switching frequency
Short-circuit protection
Voltage reversal protection
Cable length max.
Note: all data measured according to IEC 60947-5-2 standard with U
CONTRINEX AG
Industrial Electronics
MOUNTING
Embeddable
15 mm
≤ (0.81 x S
) ) mm
n
0.75 mm
≤ 15% S
r
≤ 10% S
r
45 mm x 45 mm x 1 mm, FE 360
10...30 VDC
≤ 10% U
B
≤ 200 mA
≤ 2.5 V
≤ 30 mA
≤ 0.01 mA
≤ 100 Hz
ü
ü
300 m
=20...30VDC, T
B A
route du Pâqui 5 - P.O. Box - CH 1720 Corminboeuf - Switzerland - Tel: +41 26 460 46 46 -
Fax: +41 26 460 46 40 - Internet: www.contrinex.com - E-mail: info@contrinex.com
INDUCTIVE SENSOR
BASIC
DW-AS-60x-C44
ü Highly flexible sensor solution
ü IP 68 + IP 69K
ü Active face mountable in
5 directions
INTERFACE
Indicator LED, yellow (2x)
Indicator LED, green (2x)
IO-Link
MTTF
MECHANICAL DATA
Mounting
Housing material
Sensing face material
Max tightening torque
Ambient temperature operation
Enclosure rating
Weight (incl. bracket)
Shock and vibration
=23 °C ± 5 °C.
ü Long operating distances
ü Easy click-and-lock
mounting
ü IO-Link
Sensing state (0 ≤ S ≤ S
)
r
Power supply state
ü
2204 a
Embeddable
PA GF
PA GF
2.5 Nm
-25 ... +85 °C
IP 68, IP 69K
120 g
IEC 60947-5-2 / 7.4
