Presentation; Technical Characteristics - Watts Bt-Wr02 Rf Manuel D'utilisation

A
(RF configuration button)
/
Short press
3sec press
15sec press
/
/
/
/

2. Technical characteristics

Environment. (Temperatures)
Operating /shipping et storage
Power supply
Electrical protection
Pilote wire Input (French market)
Output
Maximum Load
Radio Frequency &
RF Receiving distance
CE Directives
Your product has been designed in
conformity with the European Directives.
Classification/Contribution
2

1. Presentation

- The BT-WR02 RF receiver is a Wall mounting receiver, designed to control heating regulation
system with a wireless thermostat BT-XX02 RF / BT-XX03 RF.
- This couple (Thermostat Receiver) can also be managed by a Central to have full control of your
heating installation from one point.
A
B
B C
(green/red) (red)
Green /
Green /
Green /
Red blinking /
Green Red
Green /
Red /
Green /
Range of approximately 30m in residential environment
EN 60730-1:2017 / EN 60730-2-9:2021 / EN IEC 61000-3-2:2019 + AMD1:2021
EN IEC 61000-3-3:2013 + AMD1:2017 + AMD2:2021 / EN 55014-1:2017
EN 55014-2:2015 / EN 55024:2010 + A1:2015 / ETSI EN 301 489-3 V2.1.1
ETSI EN 301 489-1 V2.2.3 / ETSI EN 300 220-1 V3.1.1 / ETSI EN 300 220-2 V3.2.1
EN IEC 63000:2018 / Regulation (EU) 2015/1188 / Regulation (EU) 2013/813
D
C
D
(green)
/
/
Green flash
Green blinking
/
Green flash
/
Permanently green
blinking
0°C - +40°C
-10°C to +50°C
230Vac 50Hz
Class II - IP33
6 orders Pilot Wire by phase (L)
Relay 10A - 250VAC
Up to 10A - 250Vac 50Hz (2 wires L,N)
868MHz < 10mW (Bidirectional communication)
Range of approximately 100m in open space
IV / (2%)
Power ON
Instantaneous RF transmission
Thermostat or central RF init.
Reset of the receiver
Heating demand
RF reception
Pilote wire information
RF alarm
EN
