FEATURES
• Pendant loudspeaker for even audio coverage
• 20 W rated power
• 100 V line loudspeaker with 5 W, 10 W and 20 W power taps
• Easy to hang with 5 m suspension cable
• Affordable for speech and background music applications
INSTALLATION
DANGER: Overhead mounting requires extensive experience, including the calculation of the load limit values of the
installation material and regular safety inspection of all installation materials and devices. If you do not have these
qualifications, do not attempt to perform an installation yourself. Refer instead to a qualified professional. There is a
risk that devices that are incorrectly mounted and secured may come loose and fall down. This can cause serious injury
or death.
Before installation, make sure that the amplifier system to which the speaker is to be connected is switched off and
that the connection cables are de-energised!
1
Attach the cable clamp to a suitable fastening hook and connect the desired transformer tap of the cable to the signal
supply (see table).
2
Slide the ceiling cup upwards along the cable until it touches the ceiling.
6
CE 360
5 W @ 100 V green
10 W @ 100 V yellow
20 W @ 100 V red
COM blue
