Deflector Bracket Dimensions
27" (68.6 cm) Models
A. 26
/
" (68.4 cm) overall width
15
16
Cabinet Dimensions - Flush Installations
A 25" (63.5 cm) minimum cutout depth is required.
These dimensions will result in a 1/4" (6 mm) reveal on the top, a
1/4" (6 mm) reveal on the sides, and a 1/8" (3 mm) reveal on the
bottom of the wall oven.
The front face of the cleats and platform will be visible and
should be treated as a finished surface.
A
B
C
D
E
F
G
H
Front View
27" (68.6 cm) Models
A.
/
" (1.6 cm) top cleat*
5
8
B. 27
/
" (69.2 cm) minimum
1
4
width of flush inset cutout
C. 25
/
" (65.7 cm) minimum
7
8
width of opening
D. 43
/
" (109.5 cm) minimum
1
8
height of flush inset cutout
E. 42
/
" (107.9 cm)
1
2
recommended cutout height
F.
/
" (1.7 cm) side cleat*
11
16
G.
/
" x 2" (1.3 cm x 5.1 cm)
1
2
spacer the entire depth of the
cutout*
H. Recommended junction box
location
/
I. 4
/
" - 19
1
" (11.7 - 48.9 cm)
5
8
4
bottom of cutout to floor
J. 25" (63.5 cm) minimum depth
of cutout
* Cleats and spacers must be recessed 1
front of the cabinet.
A
30" (76.2 cm) Models
A. 29
/
" (76.0 cm) overall width
15
16
F
G
J
H
I
Side View
30" (76.2 cm) Models
A.
/
" (1.6 cm) top cleat*
5
8
B. 30
/
" (76.8 cm) minimum
1
4
width of flush inset cutout
C. 28
/
" (73.3 cm) minimum
7
8
width of opening
D. 43
/
" (109.5 cm) minimum
1
8
height of flush inset cutout
E. 42
1
/
" (107.9 cm)
2
recommended cutout height
F.
/
" (17 mm) side cleat*
11
16
G.
/
" x 2" (1.3 cm x 5.1 cm)
1
2
spacer the entire depth of the
cutout*
H. Recommended junction box
location
/
I. 4
/
" - 19
1
" (11.7 - 48.9 cm)
5
4
8
bottom of cutout to floor
J. 25" (63.5 cm) minimum depth
of cutout
/
" (3.5 cm) from the
3
8
A
C
D
27" (68.6 cm) Models
A.
/
" x 2" (1.3 cm x 5.1 cm)
1
2
spacer the entire depth of
the cutout*
B. 25" (63.5 cm) depth of
cutout
C. 1
/
" (3.5 cm) recess from
3
8
front of cabinet
D.
11
/
" (1.7 cm) side cleat*
16
* Cleats and spacers must be recessed 1
front of the cabinet.
A
B
D
Top View
30" (76.2 cm) Models
A.
/
" x 2" (1.3 cm x 5.1 cm)
1
2
spacer the entire depth of
the cutout*
B. 25" (63.5 cm) depth of
cutout
C. 1
/
" (3.5 cm) recess from
3
8
front of cabinet
D.
11
/
" (1.7 cm) side cleat*
16
/
" (3.5 cm) from the
3
8
3
