RCM master/slave mode
7.2 Master/slave configuration of the RCM
The operating mode, or master/slave mode, must be defined or edited for each RCM via the integral
EN
display. The following settings can be made here:
– Stand-alone
– Master
– Slave 1
– Slave 2
– Slave 3

If the display is switched off: Press any key. A menu will appear
showing the power per phase.

Press the "Esc" key (fig. 5, item 2) to display the Rittal main
menu.

Navigate to the PDU Mode menu via the Setup menu. After
selecting the PDU Mode menu, you will be asked to confirm
with the security PIN. Please follow the instructions in sec-
tion 6.1 on entering the PIN code.
30 Rittal RCM Inline Meter
