BEFORE INSTALLATION
Before installing the heater, please read the installation instructions and pay attention
to the following:
• Check before installing the electric heater that the maximum amperage of the
main fuse matches the heater parameters.
• Does the heater output (kW) match the volume (m³) of the sauna room?
In case there are any uninsulated brick, tile, glass or log walls in the sauna room,
an additional calculated volume of 1,5 m³ should be added to the sauna room for
each such square meter of the wall. The suitable output of the heater can be
found in Table 1.
• Are minimal safety distances ensured at the installation site of the heater?
Minimal safety distances between the sauna room's ceiling and walls in view of
installing the electric heater have been provided in Table 1 and Figure 1.
NB!
The manufacturer's warranty is not valid, if the output of the heater does not
correspond to the calculated volume of the sauna room.
INSTALLATION
Positioning of the heater
The heater should be positioned in such a way that there is a safe distance between
flammable materials and external surfaces of the heater.
• Check Table 1 for minimal safety distances between the heater, sauna room's
ceiling and walls.
• Place the heater in such a way that its location does not create dangerous
situations during use and the possibility of accidental contact with the heater
would be minimized.
• The input of the power cable is on the bottom cover of the heater.
Output
Table 1.
kW
CLIFF
3,5
Mini 4
CLIFF 6
6
CLIFF 9
9
CLIFF 11
10,5
*
In case there are any uninsulated brick, tile, glass or log walls in the sauna room, an additional
volume of 1,5 m³ should be added to the sauna room for each such square meter of the wall.
4
Room*
Weight
m
kg
mm
3
3,5-6
15
60
5-10
16
60
9-15
16
240
10-17
17
240
A
B
H
mm
mm
390
975
390
975
750
975
750
975
Width/
Fuse
depth
A
mm
270/160
16
270/270
10
270/270
16
270/270
16
Power
cable
N x mm
2
3 x 2,5
5 x 2,5
5 x 2,5
5 x 2,5
