3.- INSTRUCTIONS FOR THE TECHNICIAN

NOTE: When you remove the machine covers to carry out repairs or to push the
reset button, remember that the two side panels must be sealed with silicone.

3.1.- DESCRIPTION OF INTERNAL COMPONENTS

3.1.1. Iberital Intenz

a) Pump + motor: feed the hydraulic system.
b) Boiler:
c) Spring-loaded safety valve on the steam boiler.
d) Pressure relief valve on the steam boiler.
e) Boiler heating elements: heat the hot water in the boilers.
f) Expansion/check valve: controls the pressure of the hydraulic system.

3.1.2. Iberital IB7

a) Pump + motor: feed the hydraulic system.
b) Boiler:
c) Spring-loaded safety valve.
d) Pressure relief valve.
e) Boiler heating elements: heat the hot water in the boiler.
f) Pressure switch: controls the boiler pressure.
g) Expansion/check valve: controls the pressure of the hydraulic system.

3.1.3. New Iberital

a) Pump + motor: feed the hydraulic system.
b) Boiler:
c) Spring-loaded safety valve.
d) Pressure relief valve.
e) Boiler heating elements: heat the hot water in the boiler.
f) Pressure switch: controls the boiler pressure.
g) Expansion/check valve: controls the pressure of the hydraulic system.
INSTALLATION AND OPERATION MANUAL
• Double boiler:
- 2 groups 3 litres (coff ee) / 7 litres (steam/hot water).
- 3 groups 4 litres (coff ee) / 9 litres (steam/hot water).
-
• Simple boiler:
- 1 group 6 litres.
- 2 groups 10.5 litres or 14 litres.
- 3 groups 21 litres.
• Simple boiler:
- 1 group 6 litres.
- 2 groups 10.5 litres.
- 3 groups 20 litres.
• Simple boiler:
- 2 groups 10.5 litres or 14 litres
- 3 groups 20 litres.
IBERITAL
Page 63
