Using the optional cradle

The optional cradle is a device with which you can quickly connect your Android Tablet to your peripheral devices
such as a display screen, keyboard, mouse, h ea dp ho n e s , etc.
You only need to dock the tablet in order to work with your peripheral devices.
Docking
Cradle Easel
Connector
Figure 11. Cradle - Front

Setting up the Cradle

Select a suitable location for the cradle before setting it up. Observe the following conditions when doing so:
• Place the cradle on a flat, stable, non-slippery surface.
• Never place the cradle and the AC adapter on a heat-sensitive surface.
• Do not expose the cradle to extreme environmental conditions.
• Protect the cradle from dust, humidity and heat.
Cradle Base
USB Port
Figure 13. Docking Cradle Components
25 - Using the optional cradle
USB Port
DC In
HDMI Port
Figure 12. Cradle - Rear
Line Out
