Potentiometer supply
Trip memory
Acc/Dec Times
Serial communication
NPN/PNP wiring for MIx
Power terminals (general)
Terminal symbol
R/L1, S/L2, T/L3
Mains input
U/T1, V/T2, W/T3
Motor output
Connection DC-choke
+1/DC+ ~ +2/B1
(external option)
Brake resistor
+2/B1 ~ B2
(external option)
DC+/+1 ~ DC-
DC-bus connection
Ground
DELTA ELECTRONICS, INC.
ALL RIGHTS RESERVED
1x
s
RJ45
Terminal function
8 of 11
+10.5±0.5VDC/20mA
Last 6 errors
0.0 ~ 6000
Modbus RS485 COM1
Baudrate
Address
Mode
ASCII
Modbus RTU
1
*
*
Datasheet ME300
4800 ~ 38400bps
1 ~ 254
7,N,2 / 7,E,1 / 7,O,1 / 7,E,2 /
7,O,2 / 8,N,1 / 8,N,2 / 8,E,1 /
8,O,1 / 8,E,2 / 8,O,2
8,N,1 / 8,N,2 / 8,E,1 / 8,O,1 /
8,E,2 / 8,O,2
Delta reserves the right to make
changes without prior notice
