PROLUMIA LED PRO-AQUA II + Manuel D'utilisation page 10

MASTER/SLAVE FUNCTION - WITHOUT EMERGENCY
Function A
Sensor Sensor
Drawing: standard version. The connection order on the connector of the high power version is different,
but connection numbers are the same.
Function A - Central switched
MAINS POWER SUPPLY
L
Function B - Only switched by means of built-in sensors
MAINS POWER SUPPLY
L
Standard version
Single module
MAINS POWER
Remove it in
master-slave use.
10
Function B
Sensor Sensor
With sensor Without sensor
N N 1 1 2 2 N N 1 1
Optional: switch for central switching
N
On/o or high/low intensity
controlled by sensor
With sensor Without sensor
N 1 2 N 1
N
On/o or high/low intensity
controlled by sensor
MAINS POWER
Without sensor
www.prolumia.eu
Sensor Sensor
Without sensor
2 2 N N 1 1 2 2
Remove the short cable
Without sensor
2 N 1 2
Remove the short cable
The number of slaves is limited. (Max. 60 pcs)
High power version
Double module
MAINS POWER
Remove it in
master-slave use.
With sensor
Sensor Sensor
Without sensor
N N 1 1 2 2
With sensor
N 1 2
Without sensor
MAINS POWER
