Systembuild Evolution 3604408COM Mode D'emploi page 8

7a
7b
(x1)
7
#A84050
safety bracket
14
(x1)
#A55410
slide bolt
systembuild.com
Part List
Not Actual Size
7c
7d
15
17
(x2)
#A55010
handle
11b
11a
11
(x6)
#A65615
hinge
8
11d
11c
(x1)
#A55055
lock
16
(x5)
#A44710
foot
18
(x4)
#A92550
base plate kit
11e
