4.3 - TANK CLEANING
•
If the drainage tank is dirty, wash it with cold or lukewarm water.
•
Switch the appliance off and disconnect the plug from the power socket.
•
Remove the tank (7).
•
Work as described in paragraph "3.1.a".
Do not use detergent, scouring pads, chemically treated dust cloths, gasoline, ben-
zene, thinner or other solvents, as these can scratch and damage the tank and cause
water leakage.
5 - PRESERVATION OF THE APPLIANCE
If you do not intend to use the appliance for a particularly long period of time or if operations which could produce a lot
of dust must be performed, it is advised to store the appliance as follows:
•
Switch the appliance off and disconnect the plug from the power socket.
•
Empty any water remaining in the tank.
•
Clean the air filter.
•
Store in a fresh and dry place away from humidity.
6 - TECHNICAL DATA
Consult the rating plate applied to the product (Fig. 2) and the technical data listed below:
Rated Capacity
Power supply
Power Consumption
Noise
Water tank capacity
Maximum Refrigerant Charge
Net weight
Maximum design pressure
Minimum room size
Dimensions
Fuse type and rating
AQUARIA 18 P
16L / day (30°C, 80%RH)
AC 220-240V / 50Hz
240W / 1.5A
≤ 45dB(A)
5,5 L
R290 / 80g
15kg
High Side: 3.2MPa
Low Side: 0.7MPa
4 m
(floor area)
2
335 x 240 x 587 mm
T Type, AC 250V, 3.15A
AQUARIA 22 P
20L / day (30°C, 80%RH)
AC 220-240V / 50Hz
380W / 2.0A
≤ 45dB(A)
5,5 L
R290 / 85g
15kg
High Side: 3.2MPa
Low Side: 0.7MPa
4 m
(floor area)
2
335 x 240 x 587 mm
T Type, AC 250V, 3.15A
EN - 22
AQUARIA SLIM
