3.5 R emovable Wings
2 2 B
Wings support the Shoulder Bolsters which provide upper
body lateral support. The wings are width and height
adjustable to accommodate various occupants.
To Remove the Wing:
-Loosen the knob (1) and pull the wing from the receptacle.
To Insert the Wing:
- Insert the wing back into the receptacle. Tighten the knob and
ensure the wing is secured in place.
To Adjust the Wing Height:
-Loosen the knob and raise or lower the wing to the desired
position.
-Tighten the knob and ensure the wing is secured in place.
3.6 S houlder Bolsters
2 3 B
The Shoulder Bolsters provide upper torso support, protection
and containment and accommodate asymmetries in the chair
user. Their unique design allows for proper elbow access to the
arm rest. The Shoulder Bolster is always used in conjunction
with the side wing.
To Attach the Shoulder Bolsters:
-Fit the Shoulder Bolster over the wing.
-Secure with the Velcro strips.
Note: The Shoulder Bolster can be inverted on the wing in
order to provide support to narrower occupants.
3.7 Adjustable and Removable Arms
2 4
The arms on the chair are width adjustable to allow for
up to 4" (2" on either side) of additional width for the
occupant.
They are also removable to allow for side access to
facilitate safe and easy transfers.
To Remove the Arms:
1. Release both red handles and slide the arms out
until rods are completely out of the sockets.
To return, insert the rods into the sockets, ensuring the
handles are facing down, with the warning labels facing
the wheelchair. Lock the handles in place.
1
