Technical information
Application
Natural ventilation of:
• Dome rooflights
• Aluminium dark flaps
• Continuous rooflight flaps
Product features
• With overload unit for CLOSE direction and travel-dependent switch-off in OPEN direction
• For solo, tandem and group operation
• Potential-free contact for OPEN display
Contact rating: max. 230 V AC / 2 A
Nominal voltage
Current consumption
Stroke length
Lifting speed
Pressure force
Tensile force
Closure force
Protection rating
Temperature range
Duty cycle
Housing
Housing colour
Housing extension
Housing dimensions: L x W x D
Weight
Connection cable
Cable cross-section
Technical data
24 V DC ±10 %
approx. 500 mm
approx. 6 mm/s
500 N
150 N
3000 N
IP54
-10 °C to +50 °C
30 % (3 min per 10 min)
plastic
RAL 9010
RAL 9016
680 x 75 x 114 mm
approx. 2.5 kg
approx. 1.5 m
5 x 0.75 mm²
1 A
VELUX
