Connecting VHF and UHF Antennas

If your antenna has a set of leads that
look like this, see "Antennas with
300-ohm Flat Twin Leads" below.
If your antenna has one lead that looks
like this, see "Antennas with 75-ohm
Round Leads" on page 8.
If you have two antennas, see "Separate
VHF and UHF Antennas" on page 8.

Antennas with 300-ohm Flat Twin Leads

If you are using an off-air antenna (such as a roof antenna or "rabbit ears") that has
300-ohm twin flat leads, follow the directions below.
1
Place the wires from
the twin leads under
the screws on a 300-75
ohm adaptor
(not supplied).
Use a screwdriver to
tighten the screws.
2
Plug the adaptor into
the ANT IN terminal
on the back of the TV.
