IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
ASSEMBLY & INSTRUCTION MANUAL

Publicité

loading

Sommaire des Matières pour HOMCOM 824-048V80

  • Page 1 INcjh021_US_CA 824-048V80 120V~60Hz 45W IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY ASSEMBLY & INSTRUCTION MANUAL...
  • Page 3 VEUILLEZ LIRE ATTENTIVEMENT AVANT DE PROCÉDER À L'ASSEMBLAGE, À L'INSTALLATION, À LA MISE EN SERVICE OU À L'ENTRETIEN DU PRODUIT DÉCRIT DANS LE PRÉSENT DOCUMENT. PROTÉGEZ-VOUS ET PROTÉGEZ LES AUTRES EN RESPECTANT TOUTES LES CONSIGNES DE SÉCURITÉ. LE NON-RESPECT DES INSTRUCTIONS PEUT ENTRAÎNER DES LÉSIONS CORPORELLES ET/OU DES DOMMAGES MATÉRIELS ! CONSIGNES DE SÉCURITÉ...
  • Page 4 provoquer un choc électrique ou endommager le ventilateur. Ne pas obstruer ou intervenir sur le ventilateur de quelque manière que ce soit pendant qu'il fonctionne. 10. Ne laissez pas le VENTILATEUR sans surveillance. Toujours débrancher le VENTILATEUR lorsqu'il n'est pas utilisé.
  • Page 5 pas être effectués par des enfants sans surveillance. 18. Le boîtier arrière ne doit pas être démonté, son retrait pourrait s'avérer dangereux. 19. Cet appareil n'est pas destiné à être utilisé par des personnes (y compris les enfants) dont les capacités physiques, sensorielles ou mentales sont réduites, ou qui manquent d'expérience et de connaissances, à...
  • Page 6 DÉSIGNATION DES PARTIES Panneau de ommande Panneau d'affichage Sortie d' Air Base ASSEMBLAGE Sortez les deux parties de la base du carton d'emballage. Ensuite, alignez les centres des deux parties de la base et placez-les en croix. Faites tourner l'une des deux bases pour aligner l'emplacement de son trou et la faire adhérer correctement (Fig 1).
  • Page 7 (Fig 2) TÉLÉCOMMANDE Comprend une pile bouton (le type de pile CR2025). Le bouton d'alimentation de la télécommande est étiqueté comme tel. Toutes les fonctions exécutées avec la télécommande sont identiques à celles des commandes manuelles. ( Fig 3). (Fig 3) (Fig 4) MODE D'EMPLOI Le VENTILATEUR peut être commandé...
  • Page 8 ALIMENTATION Allumez le VENTILATEUR en appuyant sur le bouton 'POWER' ; éteignez le VENTILATEUR en appuyant à nouveau sur le bouton 'POWER'. 3. VITESSE : Vous pouvez régler la vitesse du VENTILATEUR au niveau souhaité : faible, moyen ou élevé en appuyant sur 'VITESSE'. Le valeur de la vitesse s'affiche sur la fenêtre LED (voir Fig 5) .
  • Page 9 fonctionnera à haute vitesse pendant 15 minutes, passera à la vitesse moyenne pendant 15 minutes, puis passera à la vitesse lente jusqu'à ce qu'il s'arrête. Vous pouvez désactiver la fonction d'oscillation manuellement. L'écran LED s'éteint si vous ne contrôlez pas le ventilateur dans les 30 secondes, appuyez sur n'importe quel bouton pour allumer l'écran.
  • Page 10 PORTE-CÂBLE : Le porte-câble est emballé avec le manuel d'utilisation, retirez-le et placez-le à l'arrière du produit. Suspendez le cordon d'alimentation au porte-câble lorsque le ventilateur n'est pas utilisé (Fig6). (Fig 6) MAINTENANCE Cette opération ne peut être effectuée que par un agent de service agréé, tel que votre revendeur local Sealer ou tout agent qualifié...
  • Page 11 Risque d'incendie. Remplacez le fusible uniquement par un fusible de 2,5 ampères, 125 volts. Faites glisser le couvercle d'accès au fusible sur le dessus de la fiche d'attachement. ATTENTION : N'essayez pas de remplacer la fiche elle-même. Jetez entièrement le produit si la fiche est endommagée. Lorsque vous remplacez le fusible, n'effectuez pas d'opération brusque ou d'effort excessif, sinon le produit sera endommagé...
  • Page 12 READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE OR MAINTAIN THE PRODUCT DESCRIBED. PROTECT YOURSELF AND.OTHER BY OBSERVING ALL SAFETY INFORMATION. FAILURE TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE! IMPORTANT SAFETY INFORMATION 1. Read all instructions carefully before using the FAN. 2.
  • Page 13 12. Do not use FAN outdoors. 13. Disconnect the fan from the mains power when not in use, and before servicing or performing any maintenance. WARNING The Main Power Switch and the On/Off switch should not be used as the sole means of disconnecting power.
  • Page 14 To avoid danger of electric shock, unplug WARNING : from outlet when not in use and before cleaning. If the supply cord is damaged, it or it’s must be replaced by the manufactory service agent or a similarity qualified person in order to avoid a hazard. PARTS NAME ASSEMBLY Take out the two parts of the base from packing box.
  • Page 15 Put the wire in the recess, then fix the base on the fan body with four screws (included), and turn the screws clockwise (Fig (Fig 2) REMOTE CONTROL 1. Included a button cell battery (the type of battery CR2025). 2. The Remote Control Power button is labeled as such. All the functions performed with the Remote Control work identically to the Manual Controls.
  • Page 16 POWER Turn the FAN on by pressing the ‘POWER’ button; Turn the FAN off by pressing the ‘POWER’ button again. 3. SPEED You can adjust the fan speed to the desired level: low, medium, or high by pressing ‘SPEED’ . The speed setting is displayed on the LED panel (shown in Fig 5) .
  • Page 17 5. TIMER The fan is equipped with a timer that allows you to set its length of operation from 1 hour to 12 hours.The LED Display will turn off if you don’t control the fan in 30 seconds, touch any button to turn on the display.
  • Page 18 (Fig 6) MAINTENANCE This can only be done by an authorized service agent such as your local Sealer dealer or any agent qualified to undertake electrical repairs. 2. If the unit requires external cleaning make sure it is switched off and unplugged from the mains supply.
  • Page 19 CAUTION: Do not attempt to replace the plug itself. Discard the product entirely if the plug itself is damaged. 1. When you replace the fuse,please don’t operate suddenly or overexert, or else the product will be damage or cause accident. 2.
