Misure Di Sicurezza - Newteck WIND PURE Mode D'emploi

2. Y ou can add the ice packs to the water tank if you want to get cooler air. Always use with water.
The water level, including the ice packs, should be between the "MIN" and "MAX".
3. C hoose the desired speed (low-mid-high) and the unit will change to the correct position
4. Press the Cooling button
Ice Packs:
The Ice Packs stay cold and slowly absorb heat from the water, thus cooling the water temperature
in the tank and blowing out colder air.
• Put the Ice Packs in the freezer for at least 6 hours.
• R emove the water tank and place the Ice Packs along with water inside.
• T wo Ice Packs are included for use according to your needs.
CLEANING
• Please disconnect the unit from the power supply before cleaning.
• D o not immerse the control panel in liquid or water
• D o not use abrasive products.
Cleaning the air filter
In the back of the unit, remove the upper screw and take out the air filter holder using the two upper
grips. Separate the filter from the damp cloth.
Clean the air filter with a neutral detergent and a soft brush, it may be cleaned with water, and then
left to dry.
Replace the filter and cloth into position and screw back in place.
Cleaning the damp cloth:
In the back of the unit, remove the upper screw and take out the air filter holder using the two upper
grips. Separate the filter from the damp cloth.
Clean the damp cloth with a neutral detergent and a soft brush. Rinse with water and leave it to dry.
Replace the filter and cloth into position and screw back in place.
ATTENTION: Place the cloth correctly in position to avoid water leakage.
Cleaning the water tank:
Clean the water tank with a neutral detergent and a soft brush, then rinse with water.
Cleaning the casing:
If necessary, clean the casing with a neutral detergent and a soft cloth.
Grazie di aver acquistato il Condizionatore portatile. Si raccomanda di leggere le istruzioni
prima di usare il prodotto e di conservarle per usi futuri.

MISURE DI SICUREZZA

• Verificare il voltaggio prima di attaccare l'apparecchio alla presa di corrente. La presa deve avere
una corrente superiore a 10A.
to activate the air cooling function.
ITALIANO
ALWAYS ASSURE THAT
THE TANK CONTAINS
WATER WHEN USING
THE COOLING
FUNCTION, OTHERWISE
THE ENGINE WILL BURN.
13
.
