6. Power up your Drive 3G-S. Connect the
power cable to the mini-USB port on the
bottom of the Drive 3G-S . Then insert the
adapter into the vehicle 12V DC power
source. Use only the supplied weBoost
power supply. While the Drive 3G-S may
remain on, leaving the Drive 3G-S on
in a vehicle when it is not running may
discharge the battery in a day or two. Also
note that some 12V DC power sources
are shut down when the vehicle ignition
is turned to off . Use a Bluetooth headset,
wired hands-free device or speakerphone for
talking on the phone .
In-Building Installation Option
Note: Home Office Accessory Kit sold
separately
1. Install the Outside Antenna to a window. For
best results:
• Select a window on the side of the building
where you get the strongest cell signal.
• Attach the suction cup bracket (sold
separately) to the inside of a window so
the cable will reach the location of the
Mounting Bracket and Drive 3G-S . Place
the bracket as high on the window as
possible .
NOTE: Many modern energy efficient dual
pane windows use a metal coating that
may decrease the strength of a cellular
signal, reducing the effectiveness of
the Drive 3G-S. If you have dual pane
windows, consider a weBoost signal
boost product that provides an option for
mounting an antenna on an outside wall or
roof of a building .
• With the bracket in place, attach the
Need help?
2.
3 .
4.
http://cellphonesignalbooster.us
magnet base of the antenna to the flat
surface of the bracket . The antenna must
be mounted vertically for the best signal.
Install the Mounting Bracket and Drive 3G-S.
Put your Drive 3G-S in the Mounting Bracket
(see instructions under Vehicle Installation)
and place it in a convenient location such as
a desk or table top in the room where you
will use the phone. The location should be at
least three feet from the Outside Antenna to
avoid oscillation (feedback) . Your cell phone
must be in the cradle for the Drive 3G-S to
amplify the signal. Use a Bluetooth headset,
wired hands-free device or speakerphone for
talking on the phone .
Attach the antenna to the Drive 3G-S .
Connect the cable from the Outside
Antenna to the antenna connector on the
bottom of the Drive 3G-S . Do NOT plug
in the power supply (next step) until the
Outside Antenna cable is connected to the
Drive 3G-S .
Power up your Drive 3G-S. Connect the
power cable to the mini-USB port on the
bottom of the Drive 3G-S . Then insert
the adapter into the AC power supply
(859969), sold separately. Use only the
supplied weBoost power supply.
5
