CARE AND MAINTENANCE
IMPORTANT: Always remove the
battery from the tool before performing any
maintenance on it.
1. REPLACING THE SCRAPER
NOTE: The scraper is located at the bottom of the
impeller housing. Ensure that the battery is not
installed in the tool.
• Remove the screw from each side plate that
holds the scraper.
• Remove the 3 screws from under the machine
that secure the scraper to the machine.
• Remove and discard the old scraper. Install
the new scraper and fasten it securely with 5
screws previously removed.
All manuals and user guides at all-guides.com
15
1
Screw
3 Screws
Screw
