ASSEMBLY
STEP 11
8
Springs (x6)
STEP 12
8
Springs (x84)
Next, place six springs into the V-rings just left of the sockets, and stretch
the springs until they reach the frame holes just left of the sockets.
You now have attached 12 springs. There should be seven V-rings and seven
frame holes in between each spring.
Enclosure door
Now, place one spring directly to the left of each spring already placed.
Continuing in a clock-wise direction, attach the remaining springs following
the pattern of placing springs directly to the left of already placed springs until
all 96 springs have been placed.
Pro tip: Keep to the pattern here. (See below for example) Placing springs one directly
after the other will cause uneven tension making placement increasingly difficult!
19th
18th
29th
17th
28th
16th
27th
15th
20th
21st
26th
25th
14th
12
(8)
22nd
23rd
24th
13th
Socket
