Smart IR: function to prevent cross fading from the reflections of objects which are too
close (function only when TRUE WDR is off, cross fading is compensated
through multiple exposure in TRUE WDR mode)

7.7.2.3 BLC

The BLC function (back light compensation) attempts to improve the appearance of objects in
front of a bright background. Identification of the object can be improved here in addition to the
WDR function particularly when it comes to close objects.
Note: if the BLC function is enabled, the digital WDR level is fixed (see later)
and can no longer be changed.
Enable: activates the BLC function. The digital WDR level is then blocked.
Level: the selection of the level -2, -1, 0, 1, 2, 3 depends on the starting scene. Make
this selection during the installation.

7.7.2.4 White balance

Mode: Select between different variants of white balance.
Automatic, manual, fixed, indoor, outdoor, fluorescent light
98
