QM5 AND QS5 HANDBOOK
May be followed by:
Single output modules
vMcde
Where:
v
= Output voltage
M
= Module name: SA, SB or SC
c
= S for screw terminal output, F for faston
d
= See letter from Module Signal Option Table
e
= C for Industrial Leakage, omit for standard leakage (60950 & 62368 only)
Optionally followed by 'Dxxx' where xxx is the number of mV of droop. Droop option available by Non-
Standard request only.
Dual output modules
v1/v2DHcde
Where:
v1
= CH1 output voltage
v2
= CH2 output voltage
DH
= Module name: DH
c
= S for screw terminal output, F for faston
d
= See letter from Module Signal Option Table
e
= C for Industrial Leakage, omit for standard leakage (60950& 62368 only)
v1/v2DMcde
Where:
v1
= CH1 output voltage
v2
= CH2 output voltage
DM
= Module name: DM
c
= S for screw terminal output, F for faston
d
= See letter from Module Signal Option Table
e
= C for Industrial Leakage, omit for standard leakage (60950 & 62368 only)
Blanking plates
B/S
Where:
B/S
= Blanking plate
Parallel combinations
vZxcde
Where:
v
= Output voltage
Z
= Paralleled output module comprising SB or SC modules
x
= Number of slots (See Parallel and Series combinations Table below)
c
= S for screw terminal output, F for faston
d
= See letter from Module Signal Option Table
e
= C for Industrial Leakage, omit for standard leakage (60950 & 62368 only)
Page 16 of 37
260362-07, Mar 2020
