Desoutter ECS Mode D'emploi page 9

B
6158101270 6158101180
Part No Designation
6158101270 Holder Diam. 36.5
(12 - 25 N.m)
6158101180 TRA Uniholder
(12 - 25 N.m)
6158108350 Tool Clamp
Diam 28.5 - 41
02/2019
ECSF - FASTENING ON THE BASEPLATE
6158108350
Clamping
position
2
2 / 3
2 / 3
B1
Possible
Clamping
area
Preferable
Clamping
area
6159935380
Issue no: 21
2
3
