GE Appliances RAVRG4 Instructions D'installation

Before you begin - Read these instructions completely and carefully.
IMPORTANT – OBSERVE ALL GOVERNING CODES AND ORDINANCES.
Note to Installer – Be sure to leave these instructions with the Consumer.
Note to Consumer – Keep these instructions with your Owner's Manual for future reference.
PARTS INCLUDED
• Return Air Grille/Access Panel
•
• Mounting Frame
• Access Panel Screws
Materials Needed (Field Supplied Parts)
•
•
INSTALLATION
OVERVIEW
Mounting
Frame
Installation Instructions
for your new
RAVRG4
Large Access Panel with
reversible hinges
and return air grille
Access Panel
Screws
Return Air Grille/
Access Panel
31-5000498 Rev. 1 03-23 GEA
Mounting
Frame
28 "
55 "
24" x 20" Nom. Filter
Filter mounts on the
inside of Access Panel
on chassis.
Return Air Grille/
Access Panel
