Astralpool FLOC SYSTEM Manuel D'installation page 6

Advanced Submenus Display
Input Config
Manual Mode
Set Point Unit
cc/m3
Statistic
Calibration
On
Flow
On
Once the type of dosing is set keep the SET key pressed for 5 seconds; the range of inlet values is modified,
pressing the Enter key and choosing using UP and DOWN, always confirming with the Enter key; the range
of values is connected with the speed of the pump (10-100%).
Dosing Methods
Input Config
Manual Mode
Input Config
mA Mode
Input Config
Pulse Mode
Input Config
Frequency Mode
* Units of measurement that can be set
Exit Menu:
To exit from the programming Menu, press the Esc key, and the system will display:
Exit
Save
Exit
No Save
0000137718
Display
The dosing methods can be accessed:
Manual mode
•
mA mode
•
Pulse mode
•
Frequency mode
•
The unit of measurement is set, which can be:
cc/m³
•
cc/l
•
Acc. Num. (Num. of times the system is
•
switched on)
Dos. Num. (Number of times the motor is
•
switched on)
Flow hours (Num. of flow hours)
•
100% hours (Hours of work at 100% of the
•
motor)
Reset all? (Resets the parameters of the
•
statistics)
Whether to activate or deactivate the calibration is set
The flow sensor is activated or deactivated
Range of values
1/1 - 999/999 cc/l or cc/m³*
With Enter it is possible to exit and save the
modifications made.
With Enter it is possible to exit and not to save the
modifications made.
rev. 1.0
Settings
Inlet 230 Vac
10 - 100%
0 - 20 mA
1 - 200 p/min
Settings
4
