English
The IZAR RECEIVER M-Bus requires around the
same amount of M-Bus current as 20 normal
M-Bus terminal equipment.
Therefore a maximum of:
ƒ
1 IZAR RECEIVER M-Bus to a IZAR CENTER 25
ƒ
3 IZAR RECEIVER M-Bus to a IZAR / HYDRO-CENTER 60
ƒ
6 IZAR RECEIVER M-Bus to a IZAR CENTER 120
ƒ
12 IZAR RECEIVER M-Bus to a IZAR / HYDRO-CENTER 250
can be connected.
The IZAR RECEIVER M-Bus can not be operated
with HYDRO-CENTER 25 devices.
The maximum cable length is limited to 100 m ...
1 km depending on the number of connected
IZAR RECEIVER M-Bus and other M-Bus devices.
Please ensure for the initial operation of the
IZAR RECEIVER M-Bus that the most recent ver-
sion of the Diehl Metering IZAR@CENTER soft-
ware is used.
6. Installation / removal
The IZAR RECEIVER M-Bus must be installed at
least 10 cm away of metallic objects (pipes,
cable).
The installation environment has to correspond to the
protective conditions of the housing (IP20).
IZAR RECEIVER M-Bus
