English
1. General information on the guide
The guide is intended for trained specialised personnel.
For this reason no basic working steps are included.
2. Package content
Please check the package content before you install or
use the IZAR RECEIVER M-Bus for the first time.
ƒ
IZAR RECEIVER M-Bus
ƒ
Wall bracket
ƒ
2 fastening screws
ƒ
2 plastic seals
3. Description
The IZAR RECEIVER M-Bus receives radio telegrams from
the IZAR RADIO modules or Diehl Metering meters with
integrated radio and saves them in the internal memory.
Each time a new telegram is received, the IZAR RECEIVER
M-Bus overwrites the old telegram of this meter.
The IZAR RECEIVER M-Bus can only be used in combina-
tion with a IZAR CENTER M-Bus Master.
An automatic, interval-controlled reading is possible as
with a normal M-Bus meter.
The data saved in the IZAR CENTER can then be transmit-
ted to the IZAR@NET software.
IZAR RECEIVER M-Bus
