Installation
Network Service Configuration
The following prompts configure the connection methods that the SNMPWEBCARD will accept.
Enable SNTP? [Y]
Enable FTP? [Y]
Port number? [21]
Enable HTTP? [Y]
Port number? [80]
Enable HTTPS? [Y]
Port number? [443]
You can also change the root password, real-time clock and other settings. (Tripp Lite
recommends against changing the default settings unless you are an advanced user with a
specific purpose.) After you have finished entering settings, the PDU will save changes to memory
and reboot (this may take several minutes). After the PDU reboots, the initialization page should
display the new static IP settings.
4-6
Remove Serial Cable: Remove the serial cable from the PDU and proceed to Step
Network Connection
5-1
Connect PDU to Network: While the
PDU is powered, connect a standard
Ethernet patch cable to the RJ-45
Ethernet port on the PDU.
Note: This port is not compatible with PoE
(Power over Ethernet) applications.
5-2
Access PDU with Web Browser: After
an IP address has been assigned to the
PDU, attempt to access it with a Web
browser that supports frames, forms
and Java™. Open a Web browser on a
computer connected to the LAN and
enter the IP address assigned to the
PDU. You should be prompted for a
password . The user name is admin
A
and the default password is admin.
After you enter the user name and
password, the PowerAlert status page
will appear in the browser window. For
more information about configuration
and operation of the PDU via the
PowerAlert interface, refer to the
SNMPWEBCARD User's Guide, included
on the CD-ROM bundled with the PDU.
Note for Network Management System
Users Only: Two MIB files - Tripplite.mib
and RFC1628.mib - must be loaded on
each Network Management Station that
will monitor the PDU via SNMP . The files are
provided on the CD-ROM included in the
product package.
201207109-93-3161.indb 7
All manuals and user guides at all-guides.com
Enable Telnet Menu? [Y]
Port number? [23]
Enable Telnet Programs? [Y]
Port number? [5214]
Enable SSH Menu? [Y]
Port number? [22]
Enable SSH Programs? [Y]
B
7
Port number? [2112]
Enable SNMP? [Y]
Port number? [161]
Enable SNMPv1? [Y]
Enable SNMPv2c? [Y]
Enable SNMPv3? [Y]
A
B
.
5-1
