RF RC M30 / RF HS M30 SW868/SW915/SW917/SW922
//
Montage- und Anschlussanleitung / Funkschalter
Mounting and wiring instructions / Wireless switch
Instructions de montage et de câblage / Interrupteur sans fil
Istruzioni di montaggio e collegamento / Interruttore wireless
Instruções de montagem e instalação / Interruptor sem fio
English
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Location
in free field (SW868/915/917)
in free field (SW922)
indoors (SW868/915/917)
indoors (SW922)
Field strength meter for range test:
Transmitter Device
SW868 swView 868 MHz
SW915 swView 915 MHz
SW917/SW922
Radio operation
The transmission of a switching command from the transmitter to the
receiver takes about 80 to 100 ms, based on the sWave® data trans-
mission. The switching signal of a transmitter must not be generated
at a shorter distance, otherwise this signal will be overlooked. The
receiver must conform to the sWave® protocol of the steute modules.
Each switching operation triggers a transmission from the radio unit.
Assignment of locations and radio frequencies:
Device type Radio frequency
SW868 868.3 MHz
SW915 915.0 MHz
SW917 917.0 MHz
SW922 916.5 MHz
Penetration
90...100%
65...95%
10...90%
0...10%
Wireless range
(approx.)
450 m
150 m
40 m
20 m
Material No.
1190393
1221794
on request
Location According to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Mounting notes
Fix the wireless switch to a suitable medium and a through-hole with
two nuts. Do not use ferromagnetic material. Install the actuator at a
minimum distance of 8 mm to ferromagnetic material. In special
cases, perform a functional test. The tightening torques are low, see
»Technical data«. The sensor part is sensitive to strikes: do not use the
front as an end stop.
Battery replacement
See section »Battery replacement«.
Safety
Do not use the device in connection with other devices whose direct or
indirect purpose is to ensure life or health, or whose operation may
pose a threat to humans, animals or material assets.
N.B.
Subject to technical modifications. Reconstruction and alterations to
the device are not allowed. It is the responsibility of the manufacturer
of a plant or machine to guarantee the correct general function.
Maintenance and cleaning
.steute recommends routine maintenance as follows:
1. Remove all dirt particles: Clean enclosure on the outside only.
Clean device in accordance with IP protection class.
Clean with a soft cloth and water or a mild detergent.
Do not clean using compressed air.
2. Replace damaged parts.
3. Test the function.
Disposal
- Observe national, local and legal regulations concerning disposal.
- Recycle each material separately. Dispose of possibly contained
batteries correctly.
ESD
Ensure adequate ESD protection for all work that requires opening
the unit.
3 / 20
