Front panel
MT424
Picture caption :
Screw cap tank: TCD (Diesel) TCE (Petrol) and TCFAP (DPF
1
Regeneration) products
Pressure Gauge
2
Connection OUTPUT
3
Pressure regulator
4
Connection RETURN
5
Transparent tube
6
Spray head
7
Atomizer screw head
8
Screw cap for RGE MT751 tank
9
START button
10
STOP button
11
EGR supply valve
12
picture a
How to replace the sprinkler:
The spray head is supplied with two sprinklers. One is already set in the spraying place (picture d), the other is screwed
on the upper part of the spray head (picture a). To replace one sprinkler by the other, unscrew the wanted sprinkler with
a flat screwdriver (picture b). Open the spray head with a size 11 wrench to reach the spraying place (picture c). Unscrew
the sprinkler to be replaced with a flat screwdriver (picture e) and exchange the two sprinklers. Reset. Screw the removed
sprinkler on the upper part of the spray head in order not to lose it.
2
4
8.1
Sprinkleers : small 38 for engine <2,5L
large 50 for engine >2,5L
picture b
1
3
5
picture c
12
7
8.1
picture d
Rear panel
MT422
6
8
picture e
