Motherboard Layout (AD2500-ITX)
1
2
3
COM1
USB 2.0
1
T: USB0
CPU_FAN1
B: USB1
Super
IO
LPT1
1
USB 2.0
T: USB2
B: USB3
20
RoHS
USB 2.0
Top:
T: USB4
RJ-45
B: USB5
LAN
PHY
CMOS
Battery
AD2500-ITX
HD_AUDIO1
AUDIO
CODEC
19
1
Print Port Header (LPT1, White)
2
COM Port Header (COM1)
3
CPU Fan Connector (CPU_FAN1)
4
CPU Heatsink
5
Chassis Fan Connector (CHA_FAN1)
6
2 x 240-pin DDR3 SO-DIMM Slots
(DDR3_A1, DDR3_A2, Black)
7
ATX Power Connector (ATXPWR1)
8
SATA2 Connector (SATAII_2, Blue)
9
USB 2.0 Header (USB8_9, Blue)
10
Infrared Module Header (IR1)
11
System Panel Header (PANEL1, White)
ASRock AD2700-ITX / AD2500-ITX Motherboard
4
5
17.0cm (6.7 in)
ErP/EuP Ready
CHA_FAN1
SATAII_1
SATAII_2
16Mb
BIOS
USB8_9
1
1
USB6_7
1
CIR1
PCI1
CLRCMOS1
SPEAKER1
1
1
Design in Taipei
18
15
17
16
14
12
Consumer Infrared Module Header (CIR1)
13
Clear CMOS Jumper (CLRCMOS1)
14
Chassis Speaker Header
(SPEAKER 1, White)
15
USB 2.0 Header (USB6_7, Blue)
16
SATA2 Connector (SATAII_1, Blue)
17
16Mb SPI Flash
18
PCI Slot (PCI1)
19
Front Panel Audio Header
(HD_AUDIO1, White)
20
Intel NM10 Express Chip
6
7
8
9
IR1
10
1
PLED PWRBTN
11
1
HDLED RESET
PANEL 1
12
13
3
