46600
Universal-Schaltnetzgerät
»Electronic 2.5«
Eigenschaften des »Electronic 2.5«
• extra kompaktes und leichtes, stabilisiertes
Netzgerät, modernste Technologie
• Leistungsstark: max 2500 mA je nach Spannungs-
bereiche!
• Dieses Netzgerät ist mit einem Schaltnetzteil
bestückt und ist deswegen leichter und effizienter
als herkömmliche Netzgeräte. Eingestellte Span-
nungen bleiben auch bei geringer Belastung stabil.
• vielfältige Anwendungsmöglichkeiten, ideal auf Reisen!
• inkl. 8 Stecker: 2 Klinkenstecker - 2,5 und 3,5 mm
6 DC-Stecker: 0,75 x 2,35 / 1,0 x 3,0 /
1,3 x 3,5 / 1,6 x 4,0 / 2,1 x 5,0 /
2,5 x 5,5 mm
• Grüne LED für Funktionskontrolle
• Polarität umkehrbar; CE-geprüft
• Farbe: schwarz
Technische Daten:
- Eingang: 100-240 V; 50 Hz/60Hz; 0,28Amax
- Ausgangsströme:
- Leistungsstark: max 2500 mA
3,0V/4,5V/5V: 2500mA
6,0V/6,5V: 2000mA
7,0V: 1900mA
- Ausgangsspannungen: 3,0 - 4,5 - 5,0 - 6,0 - 6,5 -7,0 V
Wichtige Hinweise:
• Bitte überprüfen Sie vor Inbetriebnahme des
Netzgerätes, dass die Spannung, die Stromauf-
nahme und die Polarität des zu versorgenden
Gerätes mit dem des »Electronic 2.5« überein-
stimmt. Beachten Sie hierfür immer die Hinweise
der Gerätehersteller. Für Folgen durch falsche
Spannungswahl oder falsche Polarität, sowie
Überlastung übernehmen wir keine Haftung!
• Zuerst die Spannung und die Polarität einstellen
und nun das gewünschte Gerät anschliessen. Erst
dann an der Netzsteckdose (100-240V) einstecken.
• Sollten Sie das Gerät nicht benutzen, bitte vom
Netz trennen.
• Zur Reinigung Gerät ebenfalls vom Netz trennen und
nur mit trockenem, weichem Tuch durchführen!
• Defekte Netzgeräte nicht mehr benutzen und
nicht öffnen. Reparatur nur durch den autorisier-
ten Fachmann
• Nur zur Verwendung in geschlossenen, trockenen
Räumen! Um Brandgefahr und die Gefahr eines elek-
trischen Schlages auszuschliessen, muss das Netz-
gerät vor jeglicher Feuchtigkeit geschützt werden.
• Das Netzgerät »Electronic 2.5« gehört, ebenso wie
andere netzbetriebene Geräte, nicht in Kinderhände!
Polarität
TIP
TIP
»Electronic 2.5« universal
l
mains adapter with switching facility
Properties of the »Electronic 2.5«
• Extra compact, lightweight stabilised mains adap-
ter of ultra-modern technology
• Powerful: max. 2500 mA depends on voltage ranges!
• This mains adapter is fitted with a switching unit
and is therefore lighter and more efficient than
conventional mains adapters. Adjusted voltages
remain stable, even with lower loads.
• For a diversity of applications - Ideal for travel!
• A total of 8 plugs included: 2 jack plus - 2.5 and 3.5 mm
• Green LED for function indication
• Reversible polarity; CE-certified
• Colour: Black
Technical data:
- Input: 100-240 V; 50 Hz/60 Hz; 0.28 A max.
- Output currents:
- Powerful:max. 2500 mA
3.0 V/4.5 V/5 V : 2500 mA
6.0 V/6.5 V : 2000 mA
7.0 V : 1900 mA
- Output currents: 3.0 - 4.5 - 5.0 - 6.0 - 6.5 - 7.0 V
Important remarks:
• Before using the mains adapter always check that
the voltage, current input and polarity of the device
that is to be supplied with power matches the cor-
responding specifications of the »Electronic 2.5«.
Always observe the instructions of the device ma-
nufacturer. We do not accept any liability for the
consequences of an incorrectly selected voltage,
incorrect polarity and overloading!
• First set the voltage and polarity, then connect
with the required device, and only then plug the
mains adapter in the mains socket (100-240 V)!
• Disconnect the adapter from the mains when it is
not being used!
• Likewise, disconnect the adapter from the mains
when cleaning it with a soft, dry cloth!
• Do not use a defective mains adapter. To prevent
electric shock, do not remove the cover! Refer
repairs only to qualified service personnel!
• Only use in closed, humid-free rooms! To prevent
fires and electric shock, always protect the mains
adapter from any form of moisture!
• Just as with all mains operated devices, ensure
that the »Electronic 2.5« is kept well away from
children!
Polarity
TIP
TIP
6 DC plugs: 0.75 x 2.35 /
1.0 x 3.0 / 1.3 x 3.5 /
1.6 x 4.0 / 2.1 x 5.0 /
2.5 x 5.5 mm
L
