Xplorer 870+

6. SELECT THE ADSL INTERFACE MODE

The ADSL Router supports four interface modes:
Parameters
Multimode
ANSI T1.413 issue 2
G.DMT
G.Lite Off
Your Internet Service Provider (ISP) will tell you the which setting you have to
choose. We recommend to select Multimode.
Click OK to confirm the entry.
Note: To save the settings, please select "Save Configuration" and then click "Save".

7. CONFIGURE THE LAN IP ADDRESS

The LAN connection setup entry comes with the following parameters:
Parameters
IP Address
Subnet Mask
Default Value
Default
Off
Off
Description
The Routers IP address
The subnet mask of the LAN interface
Default Value
192.168.1.1
255.255.255.0
