CRIB ASSEMBLY - SIDE PANEL ASSEMBLY
3
3a. To assemble the side
panels to the Crib,
align them to the
Headboard (4) as
shown in figure.
3b. Insert the Bolts (A)
inside the holes
provided at the top
and the lower end of
the Side Panels (8).
Similarly, insert the
Barrel Nuts (C) from
bottom and top of
the Headboard, as
shown in the picture.
3c. Tighten the Bolts (A)
into the Barrel Nuts
(C) using the Allen
Key (D) provided.
A
Bolt 2-1/5" (×4)
www.dreamonme.com/help
(A)
(A)
C
Barrel Nuts (×4)
(C)
(4)
(C)
(A)
